Al + XLPE
Power cable with aluminium conductors and XLPE insulation for 0.66/1 kV
APvVG is a power cable with stranded aluminium conductors, cross-linked polyethylene (XLPE) insulation and a PVC compound sheath, without protective covering. It combines the economy of aluminium with the thermal advantages of XLPE: ~25% more current through the same cross-section than AVVG. Designation breakdown: A — aluminium conductors, Pv — cross-linked polyethylene insulation, V — PVC sheath, G — unarmoured.
Sizes with actual technical data: outer diameter, weight and continuous current-carrying capacity in air at +25°C. For aluminium, typical cross-sections start from 16 mm². Full range per GOST 31996-2012: 2.5 — 1000 mm².
| Type / size | Cores | Cross-section, mm² | IEC equivalent | Outer Ø, mm | Weight, kg/km | Current (in air), A |
|---|---|---|---|---|---|---|
| APvVG 3×16 | 3 | 16 | NA2XY | 17.8 | 321 | 77 |
| APvVG 3×25 | 3 | 25 | NA2XY | 21.3 | 457 | 97 |
| APvVG 3×35 | 3 | 35 | NA2XY | 23.7 | 579 | 120 |
| APvVG 3×50 | 3 | 50 | NA2XY | 24.9 | 746 | 146 |
| APvVG 3×70 | 3 | 70 | NA2XY | 28.4 | 987 | 187 |
| APvVG 3×95 | 3 | 95 | NA2XY | 32 | 1286 | 227 |
| APvVG 3×120 | 3 | 120 | NA2XY | 35.3 | 1569 | 263 |
| APvVG 3×150 | 3 | 150 | NA2XY | 39.2 | 1925 | 304 |
| APvVG 3×185 | 3 | 185 | NA2XY | 43.6 | 2377 | 347 |
| APvVG 3×240 | 3 | 240 | NA2XY | 48.4 | 2972 | 409 |
| APvVG 3×300 | 3 | 300 | NA2XY | 53.6 | 3495 | 471 |
| APvVG 4×16 | 4 | 16 | NA2XY | 19.5 | 394 | 77 |
| APvVG 4×25 | 4 | 25 | NA2XY | 23.4 | 567 | 97 |
| APvVG 4×35 | 4 | 35 | NA2XY | 26.1 | 724 | 120 |
| APvVG 4×50 | 4 | 50 | NA2XY | 27.5 | 944 | 146 |
| APvVG 4×70 | 4 | 70 | NA2XY | 31.8 | 1286 | 187 |
| APvVG 4×95 | 4 | 95 | NA2XY | 35.4 | 1639 | 227 |
| APvVG 4×120 | 4 | 120 | NA2XY | 39 | 2008 | 263 |
| APvVG 4×150 | 4 | 150 | NA2XY | 43.8 | 2514 | 304 |
| APvVG 4×185 | 4 | 185 | NA2XY | 48.3 | 3054 | 347 |
| APvVG 4×240 | 4 | 240 | NA2XY | 54.2 | 3884 | 409 |
APvVG is a modern replacement for AVVG in distribution networks with a higher load. The stranded aluminium conductors are insulated with cross-linked polyethylene (XLPE), which withstands continuous heating up to +90°C (vs +70°C for PVC) and +250°C under short circuit. This gives +20–25% continuous current-carrying capacity through the same cross-section.
Advantages vs AVVG: higher current-carrying capacity, longer service life, better overload resistance. Advantages vs PvVG (Cu+XLPE): significantly cheaper and lighter. Used in 0.4 kV trunk distribution networks, supply to transformer substations and urban cable lines.
Conductors
Stranded aluminium, round or sector-shaped, 1–5 cores.
Insulation
Cross-linked polyethylene (XLPE) with colour-coded cores. Continuous heating up to +90°C, up to +250°C under short circuit.
Stranding
The insulated cores are laid up into a cable core.
Sheath
Polyvinyl chloride compound, black. No protective covering.
Cross-section of a 3-core APvVG (Al conductors in XLPE insulation and a PVC sheath)
Full product range – see the TCG datasheet
