Fire-resistant ng-FRLS LTx power cables with a mica fire barrier
TCG fire-resistant power cables for fire protection systems, emergency lighting, firefighters' lifts and other critical loads. The construction includes a thermal barrier of mica-containing tapes, which keeps the cable operational at a fire temperature of ≥750°C for at least 90 minutes. Insulation and sheath of low-fire-hazard PVC compound (ng, cat. A) with low smoke emission (LS).
FR + LS
FR + LS + armour
FR + HF + armour
| Parameter | VVGng(A)-FRLS | VBShvng(A)-FRLS |
|---|---|---|
| Application | Fire safety systems, emergency lighting, smoke extraction | Same + installation in ground and under mechanical loads |
| Conductor | Copper, stranded | Copper, stranded |
| Fire barrier | Mica-containing tape over the conductor | Mica-containing tape over the conductor |
| Insulation | Low-fire-hazard PVC compound | Low-fire-hazard PVC compound |
| Protective coverings | Unarmoured | Armour of 2 steel tapes + PVC sheath |
| Flame propagation | Does not propagate (ng, cat. A) | Does not propagate (ng, cat. A) |
| Fire resistance | FR ≥ 90 minutes (GOST R 53316) | FR ≥ 90 minutes |
| Smoke emission | 5–7 times lower vs standard PVC (LS) | Same |
| Number of cores | 1–5 | 1–5 |
| Cross-sections, mm² | 1.5–1000 | 2.5–240 |
| Voltage | 0.66/1 kV (up to 3 kV) | 0.66/1 kV |
| Standard | GOST 31996-2012, GOST 31565-2012, GOST R 53316 | GOST 31996-2012, GOST 31565-2012 |
