FR + HF
Fire-resistant halogen-free power cable with a mica fire barrier
PPGng(A)-FRHF is a fire-resistant halogen-free power cable with copper conductors, a mica-based fire barrier, and insulation and sheath made of halogen-free polymer compounds. It combines three properties: FR – fire resistance (≥ 90 min at 750°C per GOST R 53316), ng(A) – flame-retardant (does not propagate flame), HF – halogen-free. For critical loads in places where halogen-containing materials are prohibited.
Sizes with technical specifications. The geometry is the same as VVGng(A)-FRLS; fire resistance is provided by the mica fire-barrier tape, and the absence of halogens by the composition of the insulation and sheath.
| Type / size | Cores | Cross-section, mm² | IEC equivalent | Outer Ø, mm | Weight, kg/km | Current (in air), A |
|---|---|---|---|---|---|---|
| PPGng(A)-FRHF 3×1.5 | 3 | 1.5 | — | 11 | 147 | 18.5 |
| PPGng(A)-FRHF 3×2.5 | 3 | 2.5 | — | 12 | 188 | 25 |
| PPGng(A)-FRHF 3×4 | 3 | 4 | — | 14 | 263 | 34 |
| PPGng(A)-FRHF 3×6 | 3 | 6 | — | 15.2 | 335 | 43 |
| PPGng(A)-FRHF 3×10 | 3 | 10 | — | 17 | 469 | 60 |
| PPGng(A)-FRHF 3×16 | 3 | 16 | — | 19.2 | 661 | 80 |
| PPGng(A)-FRHF 3×25 | 3 | 25 | — | 22.7 | 972 | 101 |
| PPGng(A)-FRHF 3×35 | 3 | 35 | — | 25.1 | 1278 | 126 |
| PPGng(A)-FRHF 3×50 | 3 | 50 | — | 26.6 | 1742 | 153 |
| PPGng(A)-FRHF 3×70 | 3 | 70 | — | 29.6 | 2332 | 196 |
| PPGng(A)-FRHF 3×95 | 3 | 95 | — | 34.1 | 3138 | 238 |
| PPGng(A)-FRHF 3×120 | 3 | 120 | — | 36.9 | 3853 | 276 |
| PPGng(A)-FRHF 3×150 | 3 | 150 | — | 40.8 | 4768 | 319 |
| PPGng(A)-FRHF 3×185 | 3 | 185 | — | 45.3 | 5870 | 364 |
| PPGng(A)-FRHF 3×240 | 3 | 240 | — | 50.5 | 7506 | 430 |
| PPGng(A)-FRHF 4×2.5 | 4 | 2.5 | — | 12.9 | 229 | 25 |
| PPGng(A)-FRHF 4×4 | 4 | 4 | — | 15.2 | 326 | 34 |
| PPGng(A)-FRHF 4×6 | 4 | 6 | — | 16.5 | 419 | 43 |
| PPGng(A)-FRHF 4×10 | 4 | 10 | — | 18.6 | 593 | 60 |
| PPGng(A)-FRHF 4×16 | 4 | 16 | — | 21 | 844 | 80 |
| PPGng(A)-FRHF 4×25 | 4 | 25 | — | 25 | 1251 | 101 |
| PPGng(A)-FRHF 4×35 | 4 | 35 | — | 27.6 | 1653 | 126 |
| PPGng(A)-FRHF 4×50 | 4 | 50 | — | 29.3 | 2268 | 153 |
| PPGng(A)-FRHF 4×70 | 4 | 70 | — | 33.2 | 3078 | 196 |
| PPGng(A)-FRHF 4×95 | 4 | 95 | — | 37.7 | 4104 | 238 |
| PPGng(A)-FRHF 4×120 | 4 | 120 | — | 41.3 | 5088 | 276 |
| PPGng(A)-FRHF 4×150 | 4 | 150 | — | 45.7 | 6301 | 319 |
PPGng(A)-FRHF is a premium cable for the most critical loads: fire protection systems in metro systems, tunnels, data centres, nuclear power plants and on marine vessels. It combines three critically important properties:
It is used in smoke extraction and emergency lighting systems in metro systems; power supply to server equipment in critical data centres; fire protection systems of nuclear power plants and marine vessels.
Conductors
Stranded copper, 1–5 cores.
Fire barrier
Mica-based tape over each conductor. Maintains the cable's circuit integrity at 750°C for ≥ 90 minutes (GOST R 53316).
Insulation
Flame-retardant halogen-free polymer compound.
Stranding
The insulated cores are stranded together into a cable core.
Sheath
Halogen-free polymer compound (HF). When burning, it releases no corrosive gases.
Cross-section of PPGng(A)-FRHF – orange halogen-free sheath + mica fire barrier around each conductor
Full product range – see the TCG datasheet
