Al + web
Household flat wire with a separating web, aluminium
APPBN is a household wire with aluminium conductors in PVC insulation with a separating web. The cores are joined by a thin plastic web between them, which makes it easier to separate the wires during installation. Designation breakdown: A – aluminium, P – wire, P – flat, B – with separating web, N – fixed (stationary).
Sizes with technical specifications.
| Type | Cores | Cross-section, mm² | Size, mm | Weight, kg/km |
|---|---|---|---|---|
| APPBN 2×2.5 | 2 | 2.5 | 9.0×4.2 | 42 |
| APPBN 2×4 | 2 | 4 | 10.0×4.5 | 60 |
| APPBN 2×6 | 2 | 6 | 11.0×5.0 | 78 |
| APPBN 3×2.5 | 3 | 2.5 | 13.0×4.2 | 65 |
| APPBN 3×4 | 3 | 4 | 14.5×4.5 | 95 |
| APPBN 3×6 | 3 | 6 | 16.0×5.0 | 124 |
APPBN is an aluminium household wire with a separating web. The design joins two or three wires with a thin plastic web (the “base”), which simplifies installation: the wires run together but can easily be split apart when needed (for example, at branches to socket outlets).
It is used mainly for surface installation on walls in utility, plant and storage rooms. Convenient for decorative wiring in retro or industrial loft styles. Not for concealed installation in walls – choose APUNP for that.
Aluminium conductors (2 or 3)
Solid.
Insulation
PVC compound.
Separating web
A thin plastic web between the cores that tears easily during installation to separate the wires.
APPBN cross-section – 2 aluminium conductors in PVC insulation joined by a separating web
Detailed specifications – see the TCG datasheet
