Installation wire with aluminium conductor and PVC insulation
APuV is an installation wire with a single aluminium conductor in PVC insulation. It is used for fixed installation in the lighting and power networks of residential, public and industrial buildings. Designation breakdown: A – aluminium, Pu – installation wire, V – PVC insulation.
Sizes with technical specifications.
| Type | Number of wires | Conductor ⌀, mm | Insulation thickness, mm | Outer ⌀, mm | Weight, kg/km |
|---|---|---|---|---|---|
| APuV 2.5 | 1 | 1.80 | 0.7 | 3.2 | 11 |
| APuV 4 | 1 | 2.26 | 0.8 | 3.9 | 16 |
| APuV 6 | 1 | 2.76 | 0.8 | 4.4 | 22 |
| APuV 10 | 1 | 3.57 | 1.0 | 5.6 | 35 |
| APuV 16 | 7 | 4.50 | 1.0 | 6.5 | 52 |
| APuV 25 | 7 | 5.65 | 1.2 | 8.1 | 78 |
| APuV 35 | 7 | 6.70 | 1.2 | 9.1 | 104 |
| APuV 50 | 19 | 7.95 | 1.4 | 10.8 | 142 |
| APuV 70 | 19 | 9.60 | 1.4 | 12.4 | 193 |
| APuV 95 | 19 | 11.20 | 1.6 | 14.4 | 258 |
| APuV 120 | 19 | 12.60 | 1.6 | 15.8 | 321 |
| APuV 150 | 37 | 14.20 | 1.8 | 17.8 | 398 |
| APuV 185 | 37 | 15.80 | 2.0 | 19.8 | 492 |
| APuV 240 | 37 | 18.20 | 2.2 | 22.6 | 632 |
| APuV 300 | 37 | 20.10 | 2.4 | 24.9 | 784 |
| APuV 400 | 61 | 23.20 | 2.6 | 28.4 | 1040 |
APuV is a widely used installation wire for fixed installation in the lighting and power networks of buildings. A single aluminium conductor with PVC insulation. It is used for wiring electrical installations with a rated voltage of up to 450 V (up to 750 V in 450/750 V networks).
The main application is electrical wiring in residential, public and industrial buildings and the connection of electrical appliances. It is laid in cable ducts, conduits and trays, in walls and ceilings. Where aluminium is connected to copper contacts, special Al-Cu connectors are required to prevent electrochemical corrosion.
Conductor
Aluminium, solid (for cross-sections up to 16 mm²) or stranded (25 mm² and above) per GOST 22483. Class 1 or 2.
Insulation
PVC compound. Thickness from 0.7 to 2.6 mm depending on the cross-section. Colour coding per GOST: blue – N, yellow-green – PE, brown/black/grey – phases.
APuV cross-section – aluminium conductor in PVC insulation
Detailed specifications – see the TCG datasheet
Specify the cross-section and quantity and we will prepare a proposal within 1 business day.
